BMAD Refrigeration System
Ensures rapid and effective cabinet cool down and maintains consistent temperature range with minimum energy consumption
Electronic Temperature Controller
Assures the optimal performance of the cooler, delivering product temperature ideal for consumption.
High Efficiency Glass Door
Equipped with double panel glass and low-e film to reduce condensation. Door hinge is equipped with a self-closing system to ensure the door closes safely, and returns to original position, without any damages.
LED Lighting System
Our LED system uses a fraction of the energy of regular fluorescent lights and requires no replacement for up seven years.
CFC and HFC Free Cyclopentane Foam
Eco-friendly, recyclable and high efficiency cabinet insulation.
Electronic Fan Motors
Enhances performance and efficiency. Uses only a fraction of the energy than industry standard shaded-pole motor requires. Longer lifespan fan motor.
Low Maintenance Condenser
Imbera's finless condenser designed to minimize maintenance. Drastically reduces Total Cost of Ownership. Prevents dust that blocks air flow, to save energy and extend the life of the compressor.
Customization Option: Insight - Health Lock
Imbera’s electronic heath lock system ensures door will lock if Tmax temperature & timers are exceeded. Google cloud connectivity and monitoring capability, provides optimal food safety at the point-of-purchase.Please note: Insight-Health Lock cannot be retro-fitted and must be specified at the time of order. Adding Insight-Health Lock will be considered special orders. Please refer the Return Policy for Special orders.
- Gross Weight: 320 lb
- Gross Dimensions: 48" x 40" x 89"
- UPC Code: 690207411619
- Price Label: PC
- Country of Origin: MEXICO
- Certification: Energy Star, cULus, Classified UL EPH
- Warranty: 3 Year Parts and Labor; 5 Year Compressor Warranty
Technical Specifications
|
Feature |
Specification |
|---|---|
|
Volume |
19.2 ft³ / 543.6 liters |
|
Doors |
1 |
|
Shelves |
5 |
|
Shelf Size |
24 3/4" x 19 5/8" |
|
Capacity |
20 oz - Total: 240, Front: 8 / Gravity Feed: 240 |
|
Temperature Range |
0°C - 7°C / 32°F - 44.6°F |
|
Energy Consumption |
3.040 kWh/day* |
|
Electrical |
115V / 60Hz / 1Ph |
|
Cord Length |
118" / 3000 mm |
|
Horsepower |
1/4 |
|
Amps |
5.2 |
|
Interior Dimensions (WDH) |
25 1/2" x 21 3/8" x 60 1/2" |
|
Net Dimensions |
29 1/2" x 27 1/2" x 78 3/4" |
This equipment is intended for use in an indoor environment where ambient temperature and humidity do not exceed 24°C / 75°F and 55% relative humidity.
