Standard Features
- Brew Capacity: Up to 160 cups (12 gallons) of coffee or tea per hour
- Dual Voltage: Field adjustable for both 120v2 Wire+Ground or 208-240v3 Wire+Ground
- Sprayhead Technology: Evenly distributes water over coffee grounds for uniform extraction and consistent flavor
- Pre-Infusion: Allows grounds to bloom prior to the brew cycle for improved extraction and flavor
- Pulse Brew: Uses timed water pulses to promote even saturation and consistent extraction
- Energy-Saver Mode: Reduces tank temperature during idle periods to conserve energy
- Brew Counter: Tracks total brew cycles for maintenance scheduling and usage monitoring
- Programmable Brew Recipes: Saves customizable brewing parameters for simplified one-touch operation
- USB Programming for easy settings upload
- Single and twin models available, both with a hot water dispenser
- Estimated Hot Water Recovery Rate: 3.0–3.7 gal/hr at 1440W, 4.6–7.4 gal/hr at 2180–2880W.
- Stainless steel body for durability and easy cleaning
- Supports standard 1–1.5 Gal and larger coffee servers or tea dispensers
- 5” color touchscreen with programmable brewing and intuitive digital controls
- Water inlet is 3/4” MNPT with water pressure at 7.3 – 87 psi and water flow rate at 0.05 – 0.6 Mpa.
- Includes a 3/8” O.D. Push-To-Connect x 3/4” FNPT water inlet connector and 3/8” O.D. tubing for easy water line installation
- For operation and heat dissipation, leave at least 5-7/8” (150mm) of clearance on all sides of the equipment.
| Models | Capacity (gal/L) | Voltage (V/Hz/Ph) | Power (W) | Amps (A) | Plug Type | Exterior Dimensions (inch/mm) | Package Dimensions (inch/mm) | Net Weight (lb/kg) | Gross Weight (lb/kg) |
|---|---|---|---|---|---|---|---|---|---|
| CB3L011 | 1/3.79 | 120/208-240 60Hz | 1440/2180-2880 | 12/10.4-12 | NEMA 5-15P Standard)/ NEMA L14-20 (Optional) | 11" 5/8 x 21" 7/8 x 28" 1/2 / 293 x 554 x 723 | 14" 5/8 x 26" x 30" 3/4 / 370 x 660 x 780 | 36.44/16.53 | 46.30/21 |
ETL Listed Certifications
Our products have been tested and certified through independent testing and periodic follow-up inspections by an NRTL. Our products comply with requirements of widely accepted product safety standards in the US and Canada.
1 Year Parts and Labor Warranty
Atosa warrants all new equipment components, such as the cabinet and all parts, to be free from defects in materials or workmanship up to a period of one (1) year. For full warranty download the spec sheet for this product.
