Product Highlights
Stainless steel front and galvanized sides
Cast iron open burners, each 30,000 BTU/hr
Welded frame structure for best stability
24" griddle plate (¾" thickness), with a splash guard
Adjustable heavy-duty legs
Anti-clogging pilot over under the grate
Pull-out crumb tray with angled handle in the front
U shape oven burner
Thermal coupling safety valve for the oven
Stainless steel oven door with good insulation
Stainless steel handle for bottom oven
Kick plate at the bottom for easy access to servicing
Compatible with ¾" NPT gas connection (Gas Hose sold separately)
Technical Specifications
Feature |
Specification |
|---|---|
Gas Type |
Natural |
Number of Burners |
6 Griddle Plate |
BTU |
282,000 BTU (Burner: 30,000 BTU / Griddle: 20,000 BTU / Oven: 31,000 BTU) |
Oven Temperature Range |
250°F – 550°F / 121.1°C – 287.8°C |
Oven Dimensions (WDH) |
26.6" x 23.5" x 13.9" |
Burner Dimensions |
12" x 12" |
Dimensions (WDH) |
32.6" x 60" x 60.4" |
Weight |
683 lb / 309.8 kg |
